Custom Catamaran Inc USCG COI Pilot House for sale in Treasure Island, Florida United States of America

Custom-Built High-Speed Passenger Catamarans

This is a true ocean-going "Subchapter T or K" Passenger Catamaran rated for the open ocean.

Pricing will vary widely for each build due to component pricing and availability.

The hull is rated for up to Four (Quad) 600hp Mercury engines for a total of 2,400hp if you desire to get your passengers there in a hurry!

Shallow Water Draft of less than 24".

Fuel Capacity: (2) Two 150 Fuel Gallon Tanks = 300 Gallons total. **Larger optional fuel tanks available as needed for larger motor hp sizes, fuel consumption and the desired distance needed to travel without refueling.

Fresh Water Tank Capacity: (2) Two 125 Gallons = 250 Gallons total.

Black Water Tank Capacity: 200 Gallons.

• Above deck head with pressure freshwater lavatory.
• Electrical panels, navigation lights, horn, (2) 12V batteries, Captain’s custom console, compass, (2) Tachs, trim, fuel gauges, swivel helm seat on a taller pedestal.
• Perimeter seating including storage within.
• Dual UFLEX hydraulic steering systems for our standard (2) Mercury 150 HP engines.
• VHF radio.

• Anti-skid on front deck and walkways.
• 40” Tall Aluminum Perimeter Railings with 4” maximum spacing within the railing.
• Four (4) Boarding Gates, Sizes TBD.
• The overhead custom canopy covering approx 2/3rd of the deck, allowing the bow area open for sunning.
• Motors installed and vessel totally rigged (Turn-Key).
• Boarding ladder.

• Gasoline or Diesel Outboard Power.
• Drop Down Curtains – Heavy gauge, clear sheet vinyl with canvas trim.
• Solid Color Sunbrella Canvas on Perimeter Railing.
• Custom Names, Lettering, Phone, Website, Coloring, Logos on Sunbrella Canvas Railing.
• Pressure Fresh Water cooling misting systems (Multi Spraying Heads).
• Pressure Freshwater spray down with hose & nozzle.
• Spotlight remote control.
• Ship to Shore Power, cord with Inlet and Battery Charger.
• Custom “Kicker” Stereo system w/ Subs, Horns & Amps.
• Marine Audio - PA system with (6-speakers).
• Underwater lighting.
• Diesel Generator, Ship to Shore Power with Inlet, Cord, and Battery Charger / Inverter.
• Davit crane.
• Diving board.
• Other custom options upon request.

To be built in the same 14’ x 24’ location in lieu of the standard canvas canopy.

It will be an all-weld structure and then welded directly to the aluminum decking.

• 40” Tall Aluminum Perimeter Railings with 4” maximum spacing within the railing.
• (1) lockable gate on each side of the upper deck. (Operable to open for jumping into the water).
• Access ladder to upper deck mounted at the bow area at the center of the upper deck.
• 12’ Water Slide mounted in the center stern area of the upper deck. The passengers will slide to enter the water past & between the motors area.

• LED “RGB” Light Colors & Package(s):
• Under main overhead canopy & within passenger area.
• Under deck perimeter.
• Exterior perimeter sections (TBD).
