NAUTICAL DEVELOPMENT Offshore 40 for sale in Johns Island, SC United States of America

Located in Johns Island, SC, this Offshore 40 was designed as an ultimate cruising yacht.
She is massively strong, with state of the art grid construction throughout, a solid glass hull, deck joined to hull by a double flange system, and internal lead ballast encapsulated in the keel cavity. She is a moderate displacement yacht, fast, stable, and easy to handle.
The owners of Pathfinder have lived aboard and upgraded her cruising and living accommodations.
Located in Johns Island, SC, this Offshore 40 was designed as an ultimate cruising yacht.
She is massively strong, with state of the art grid construction throughout, a solid glass hull, deck joined to hull by a double flange system, and internal lead ballast encapsulated in the keel cavity. She is a moderate displacement yacht, fast, stable, and easy to handle.
The owners of Pathfinder have lived aboard and upgraded her cruising and living accommodations. She has undergone a refit over the last few years and stands ready to cruise any time, anywhere.
Be sure to see the "Full Specifications" section for all of the equipment that has been installed!
Don't wait, call or email now!
Boat Name
Pathfinder
Specs
Flag of Registry: United States
Keel: Other
Hull Shape: Monohull
Dimensions
LOA: 40 ft 0 in
Beam: 13 ft 4 in
LWL: 35 ft 0 in
Maximum Draft: 5 ft 2 in
Displacement: 23500 lbs
Ballast: 9000 lbs
Bridge Clearance: 54 ft 5 in
Engines
Engine 1:
Engine Brand: Perkins
Engine Model: 4-108
Engine Type: Inboard
Engine/Fuel Type: Diesel
Drive Type: Direct Drive
Tanks
Fresh Water Tanks: (150 Gallons)
Fuel Tanks: (64 Gallons)
Full Specifications
Main salon
From your first view of the main salon, you know the Offshore 40 is built for family comfort. L-shaped settee to starboard and straight settee to port Beige ultra suede upholstery. Storage behind and beneath both settees. Shelving and cabinetry above and outboard of settees. Large centerline drop-leaf dining table that lowers to cocktail table height and can be used to convert starboard settee to double berth. Fitted with large center drawer for bottle storage.

• LED lights overhead and under cabinets
• Lots of ventilation: Two overhead deck hatches with hinged teak-frame screens provide excellent ventilation, eight opening ports with screens and curtains
• Storage compartments and water tanks beneath cabin sole
• Flat screen TV with built in DVD player installed 6/2014

Master Stateroom Aft
The master stateroom features a centerline queen berth with step-up access on both sides, two transom portlights, and drawers and storage lockers beneath berth

• Walk-through entry port and starboard
• Cane front cedar-lined double hanging locker, three cane front storage cabinets, full length mirror, drawer storage.
• Shelving and lift out tray storage lockers port and starboard
• Five opening ports, two overhead hatches
• Stainless steel fuel tank beneath berth, sealed storage lockers beneath sole

Head
Located in port walk-through immediately aft of nav station

• Separate full-sized stand-up fiberglass shower stall with room to turn around
• Contoured fiberglass sink and vanity top
• Hot and cold pressure water service
• Overhead hatch, opening port
• Approx 6'3 headroom throughout, including shower
• New Raritan Marine Elegance macerating electric toilet and all toilet hoses replaced with new y valve 10/2014

Guest Stateroom Forward
The V berth features custom fitted linens, satin varnished teak cabinets, and teak battens lining the hull. There is a vanity with stainless steel sink and hot/ cold pressure water.
Galley
Aft of the starboard salon settee and forward of the walk-through to the aft cabin is the galley with an extremely large and pleasant work area. There is generous counter space and storage including rattan cane-front sliding storage cabinets above and outboard, rattan cane-front cabinets beneath sink, three drawers below counter, pantry cabinet with shelves, and across the aisle from the stove is a pull out garbage bin.

• Twin stainless steel sinks with hot and cold pressure water faucet, filtration system, manual foot pump, New 6/2014
• Force 10 2-burner propane stove with oven
• 1700 series Raritan water heater, model/2015
• Four 10lb aluminum LPG tanks in a deck locker w/ solenoid system.
• Adler/Barbour CU100 and VD152 cold machine and evaporator refrigeration system 2/2016
• Katadyn Power Survivor - 40E watermaker installed 4/2015

Nav Station
Located aft of the port settee in the walk-through to aft cabin, the oversized chart table has three drawers storage beneath, an instrument panel, AC-DC electrical panel, and red/white lighting.

• Garmin GHP Reactor Mechanical auto pilot with GHP 12 Class A Drive Unit with arm attached to rudder post New 12/2016
• Autohelm wind and depth instruments are fed into a Raymarine ITC-5 analogue to digital convertor and the information is fed into the NEMA 2000 backbone data link to Garmin chartplotter
• 5" Richie Globemaster compass mounted on binnacle
• 12v outlet
• EPIRP (Global fix pro 406MHZ GPS epirp) 10/2014
• West Marine WM 4000 stereo with bluetooth connectivity 1/2015
• SSB ICOM M802 3/2015
• ICOM AT140 back stay tuner 3/2015
• Garmin GPS MAP 840 XS chart plotter 3/2015
• VHF radio with AIS receiver, Standard Horizon GX2200 AIS/GPS 3/2015
• Pactor 2 modem with a firm ware upgrade to Pactor 3 speeds for sail mail 3/2015

Hull Construction
Molded solid hand laid single piece fiberglass hull strengthened with integral fiberglass longitudinal and traverse stringer system - no wood below the cabin sole
Single piece molded fiberglass deck with Baltec balsa core, Tread Master non skid, deck fastened and bonded to hull on internal flanges

• Aluminum rub rail
• Double I-beam chain plate system
• Modified fin keel with internal lead ballast
• Skeg-hung balanced rudder
• Pedestal mounted wheel steering with cable and quadrant
• Keel stepped mast mounted on raised platform
• New bottom paint December 2016

Cockpit

• Bimini, dodger, and full enclosure over the center cockpit
• Steering pedestal
• Varnished teak cockpit table and drink holder
• Deck prism over engine room
• Plexi-glass companionway doors
• Cockpit cushions
• Stereo speakers
• 12v outlet at steering pedestal
• TV and phone inlet
• Navpod and new Angle guard 3/2015

Deck

• Twin stainless steel bow rollers
• Stainless steel bow and stern pulpits
• Stainless steel stanchions with double lifelines
• Gates fore and aft as well as port and starboard
• Two foredeck lockers- The forward most locker houses electric windlass, anchor chain, hawse pipes, wash-down spigot and room for anchor storage, second foredeck locker provides storage for lines, fenders etc
• Two side-deck lockers contain propane bottles and shore power connections respectively
• Twelve aluminum opening ports
• Four dorades
• Varnished teak hand rails
• Six deck cleats, two each forward, amid-ship and aft
• Two storage lockers on aft cabin top
• SS outboard engine hoist and mount
• Fiberglass deck box on aft deck
• All hatches replaced with Lewmar Ocean hatches 10/2014
• New stainless steel safety lines 10/2014
• Non skid replaced with Kiwi Grip 5/2016
• Mantus bridal with stainless steel anchor chain hook 10/2015
• New Martek 600 davit system plus custom solar panel mount installed 7/2014
• Magma BBQ 3/2015

Ground Tackle

• 45# CQR with 150' SS chain
• 44# Rocna with chain and nylon rode
• Lofrans Tigress electric double capstan windlass with foot control on bow and up/down switch at cockpit pedestal
• Foot control on bow new 6/2016

Sails and Rigging

• P=43', E=14.5', I=50', J=18.5'; Easy handling single spreader cutter rig with self-tending staysail, keel-stepped aluminum mast and boom with 3/8" 1x19 stainless steel strand upper and lower shrouds, 5/6" stainless steel intermediate stays, lines led aft to cockpit
• Profurl roller furling on genoa and staysail
• Profurl In-mast furling main sail system
• Hood dacron roller furling main sail
• Quantum genoa new 2012
• Quantum self tending staysail new 2012
• Five Lewmar winches, #48 two speed primaries, #24 halyard and sheets, #30 sheet and furling, and #24 halyards
• Mast pulled, sand blasted and repainted 4/2013
• Standing and running rigging renewed 4/2013
• New tri-color LED light on top of mast 4/2013
• Shore spinnaker shoot 10/2014
• ATN mast climber 6/2015
• Rebuilt roller furling staysail 2018

Tanks and Plumbing

• On demand, hot and cold pressure water service to galley, head and shower, and forward cabin via stainless steel manifold and 12v pressure pump
• 64 gal fuel in single stainless steel fuel tank located beneath aft cabin berth
• 150 gal water in two fiberglass water tanks integral to the hull - located beneath cabin sole
• 6 gal 110v hot water heater with engine heat exchange system
• 12v fresh water deck wash down pump
• Filtration system for galley
• All new bronze through hull valves 4/2013
• New shower sump pump 4/2013
• Air conditioning circulating pump LC-3CP-MD installed 5/2013
• New bilge pump and switch. 6/2013
• New 60 psi fresh water circulating pump installed 6/2013

Electrical

• Xantrex Freedom 458 inverter/charger interface system new 10/2016
• E Marine E20 solar wind controller
• Three 12 v DC Gel acid 4D type batteries 675 amp hrs
• Air Breeze wind generating system on custom, stainless braced and backed pole on aft pulpit, starboard.
• Fused, 120v AC duplex outlets.
• 75' copper bonding added with oversize dynaplate ground plates.
• Honda generator 2000 watt
• Balmar 100 amp alternator with smart regulator
• Two 30 amp shore power inlets
• AC/DC electrical panel
• Kyocera 250 watt solar panel installed 7/2014
• E-Marine E20 wind generator/solar PV control panel installed 7/2014
• New engine starter motor 8/2014
• 4 Caframo 3 speed interior fans installed 3/2015
• Serpentine Pulley Kit for alternator, Bowman heat exchanger and engine coolant reservoir installed 6/2015
• Magnum ME-SBC smart battery combiner 10/2015
• Majority of internal lights replaced with LED bulbs 11/2015
• Dual smoke/CO2 detector installed 11/2015

Engine and Mechanical

• The engine room has access from three sides and the engine is totally and easily serviceable.
• Perkins 4-108 engine
• Hurth HBW-150 2R reduction gear
• Stainless shaft
• Fixed three bladed 17/11 left hand bronze prop
• Numerous spares including two blade prop
• Racor fuel filter
• Four new engine mounts 1/2015
• New cutlass bearing 1/2015
• New propeller 1/2015

Tender

• Caribe RIB 10' hard bottom dinghy 2006
• 15hp Yamaha 2 stroke outboard 2006

Recent Upgrades

• Mast pulled, sand blasted and repainted 4/2013
• Standing and running rigging renewed 4/2013
• New tri-color LED light on top of mast 4/2013
• All new bronze through hull valves 4/2013
• New shower sump pump 4/2013
• New Lifesling 2 MOB recovery system 4/2013
• Air conditioning circulating pump LC-3CP-MD installed 5/2013
• New bilge pump and switch. 6/2013
• New 60 psi fresh water circulating pump installed 6/2013
• Flat screen TV with built in DVD player installed 6/2014
• New stainless steel double sink and taps 6/2014
• New Martek 600 davit system plus custom solar panel mount installed 7/2014
• Kyocera 250 watt solar panel installed 7/2014
• E-Marine E20 wind generator/solar PV control panel installed 7/2014
• New engine starter motor 8/2014
• EPIRP (Global fix pro 406MHZ GPS epirp) 10/2014
• All hatches replaced with Lewmar Ocean hatches 10/2014
• New stainless steel safety lines 10/2014
• New Raritan Marine Elegance macerating electric toilet and all toilet hoses replaced with new y valve 10/2014
• Shore spinnaker shoot 10/2014
• Four new engine mounts 1/2015
• New cutlass bearing 1/2015
• New propeller 1/2015
• West Marine WM 4000 stereo with bluetooth connectivity 1/2015
• Magma BBQ 3/2015
• SSB ICOM M802 3/2015
• ICOM AT140 back stay tuner 3/2015
• Garmin GPS MAP 840 XS chart plotter 3/2015
• VHF radio with AIS receiver, Standard Horizon GX2200 AIS/GPS 3/2015
• Pactor 2 modem with a firm ware upgrade to Pactor 3 speeds for sail mail 3/2015
• 4 Caframo 3 speed interior fans installed 3/2015
• Katadyn Power Survivor - 40E water maker installed 4/2015
• New Marine air 8000 BTU A/C unit in aft cabin with a Passport IO digital controller 4/2015
• 1700 series Raritan water heater, model/2015
• Serpentine Pulley Kit for alternator, Bowman heat exchanger and engine coolant reservoir installed 6/2015
• ATN mast climber 6/2015
• Magnum ME-SBC smart battery combiner 10/2015
• Mantus bridal with stainless steel anchor chain hook 10/2015
• Majority of internal lights replaced with LED bulbs 11/2015
• Dual smoke/CO2 detector installed 11/2015
• New memory foam Queen size mattress 11/2016
• Adler/Barbour CU100 and VD152 cold machine and evaporator refrigeration system. 2/2016
• Non skid replaced with Kiwi Grip. 5/2016
• Installed new macerator and all new head hoses 2017
• New head control unit
• New inverter
• New anti syphon
• New pressurized 4 stage water filtration unit under galley sink and faucet for drinking water installed at galley sink counter (ran off pressure water system after the 5 micron charcoal filter)
• All new exhaust hose 33
• All new raw water intake hose for engine
• Entire new water pump assembly on engine
• All chainplates rebedded
• New stereo deck
• New main bilge pump
• 2 fans installed in V Berth
• New bow light and all new wiring running to the light
• New diesel deck fill point
• New mainsail halyard and tackle
• New running rigging for dingy davit and motor hoist (new lower triple block for lower portion of motor hoist
• Engine fully serviced, all fluids changed
• All new 30 3/4 snubber bridle and shackles
• About half of the blocks and guide blocks for running rigging have been replaced
• New water pump assembly on Yamaha outboard
• New kill switch on Yamaha outboard
• 2 new large zincs on shaft

Additional Units Included

• 2006 Caribe 10' Hard Bottom
