BLUE REFLECTION is a modern, sporty Jongert 2100s with exceptional sailing performance and supreme comfort. The double helm position in the aft cockpit affords an optimal view of the sails and the entire deck. Thanks to the balanced rig and underwater hull, this yacht has excellent sailing and rudder characteristics. Top-class workmanship, reliability and safety complete the superb sailing characteristics.
BLUE REFLECTION is a modern, sporty Jongert 2100s with exceptional sailing performance and supreme comfort. The double helm position in the aft cockpit affords an optimal view of the sails and the entire deck. Thanks to the balanced rig and underwater hull, this yacht has excellent sailing and rudder characteristics. Top-class workmanship, reliability and safety complete the superb sailing characteristics. The successful mix of classical boat-building, state-of-the-art technology and the individual wishes of the owner, gives this yacht her very own character and charm.
The light interior furnishings along with the teak flooring throughout the yacht, creates an especially elegant and welcoming atmosphere. Amidships sits the Saloon which provides a large dining table comfortably seating six people. The Navigation area inside the yacht features chart table and all the modern navigation equipment. The fully-fitted, professional, galley is situated to starboard. The engine room is easily accessible. There is plenty of storage space in the garage where there is also an integrated bathing platform for those “crystal clear water” swims. The semi-open deckhouse, with canopy, provides excellent protection from the wind and rain should you ever get caught out on a voyage. Overall she is an exceptional yacht and would make an amazing holiday experience for any future Yacht Owner.
Hull And Deck
New teak deck 2012
Hull, topsides and mast newly painted 2012
The semi open deckhouse with canopy merges dynamically with the yachts overall lines. Well protected from all weather, this is an area to enjoy a relaxing “sundowner” or comfortably have dinner at the extendable table. The double helm position at the aft of the yacht has excellent visibility and would make any sailor happy. There is a fully equipped navigation table.
Winches: Lewmar - winches; 4 x hydraulic, 7 x manual
Windlass: Lewmar w6 (new 2006)
Anchor and Chain CQR 40 kg
Deck Shower
Deck Wash System
Bathing Ladder
Gangway
Awning
Sunbathing Mattress
Canvas Cover (New 2010)
External Rigid Covered Cockpit
Engine
MAIN ENGINES HP (KW) : CUMMINS 6 BT 5.9 m, 220 hp CYLINDERS : 6-cylinder in-line
YEAR : 2014
GEAR BOX : ZF
FUEL SEPARATOR : RACOR
PROPELLER : MAX, 3-bladed folding (2003)
BOWTHRUSTER / HP (KW) : HYDROMAR 17.5 kW
Speeds: Max: 10 knots Cruising: 9 knots
Range under power: 550 miles
CONSUMPTION : 28 litres/hour at max running
Plumbing And Ventilation
Water Maker: HEM 210 lt/hr
Hot Water Heater
Ventilation System
Heating system Webasto
Electrical
Generators/KW: KOHLER 19 kW
Consumption: 3 l/h
Inverter:
Transformers/Convert: 2
Batteries: 2005, 1 group of engine 300 Ah , 1 group for service 1000 Ah
Battery Charger: 2 x MASTERVOLT 100 Ah each (2008)
Shore Power: 220 V
Communication Equipment
GSM : SAILOR 1000 with DSC (2006)
1 x EACOM VHF-RADIOTEL: SKANTI TRP 8253 S
Internet
Emergency Transmitter: Included in VHF DSC
Tank Storage
Fuel Tank: 1600 litres in keel
Fresh Water Tank: 2 x 750 litres in keel
Waste water tank (Black): 400 litres
Waste water tank (Grey): 600 litres
Galley Equipment
Miele Microwave/ oven
Miele Stove
Nespresso coffee maker
Two fridge/Freezer
AEG washer/ dryer
Entertainment Equipment
Lorez TV/VIDEO TV with navigation system monitor
Sony DVD/CD PLAYER
Alpine RADIO/HIFI system
Interior
SLEEPS SIX GUESTS IN THREE CABINS PLUS 1 CABIN WITH TWO CREW
Owner Cabin
The owner’s cabin is aft and features a large double bed and a seating area. Plenty of storage space and a spacious en suite with toilet, sink and separate round shaped shower stall, completes this beautiful furnished area.
Guest Cabins
The two guest cabins are forward and both have upper and lower bunks. The upper bunks can be folded away and the lower bunks can be pulled out to make a more spacious bed. Both cabins are en suite with toilet, sink and separate round shaped shower stalls.
Crew Cabin The crew cabin can be accessed via the deck. This cabin has two bunks and a toilet and sink. This cabin also has access to one of the guest en suites.
Saloon
The beautiful and spacious saloon has a dining/ seating area to starboard with an open plan galley and navigation area to port.
Navigation Instruments
AUTOPILOT: ROBERTSON AP 20 with 1 head and 1 helm position (2003)
SESTRAL Compass plus ROBERTSON Gyro compass plus B & G Halycon flugate compass
FURUNO GPS/PLOTTER GP 32 GPS (2003)
FURUNO GP300 with navigation system SWAN (2009)
RADAR : FURUNO 8050 DA 48 Miles (2003)
WEATHER FAX : FURUNO DFAX
BAROGRAPH
SUMLOG : B & G
ECHO SOUNDER : B & G
WIND SPEED & DIRECTION : B & G HERCULES CLOSE HAULED & RUNNING
B & G RUDDER ANGLE INDICATOR VDO
Rigging
RIG: NIRVANA,checked 2012
Mast Height from waterline: 32.10 m
MAST repainted 2012
BOOM
SPINNAKER BOOM : 2
REEFING SYSTEM: RECKMANN hydraulic for Genoa (refurbished 2005)
RECKMANN mechanical for Jib (2005)
Sails
MAIN : DOYLE (2008)
GENOA : DOYLE (2008)
JIB : DOYLE (2006)
YANKEE : Reacher DOYLE (totally new)
SPINNAKER : DOYLE (2002)
SAIL AREA : 257.9 sqm
Safety Equipment
Life Raft for 8 persons
Life Jackets 8 persons
Life Belts 8 persons
Distress Flares full set according to CEE rules
Epirb - Sailor
Safe – Don Buoy
Zodiac atoll (2009)
Bilge Alarm new installation 2010
Fire Extinguishing Inst (refurbished 2010)
Fire Extinguisher 6 in total
Tender And Toys
Tender Novamarine 320 rigid hull
Snorkelling Equipment
Diving Equipment
Diving Compressor Bauer
Additional Information
REFIT 2012
New teak deck and new coat hull
New computer modem + charts
Dismounting and total revision of all the " on deck " gear
Stripping of the complete old deck and apply of new primer + new sealing caulking base
Complete marine plywood deck base + complete new teak deck with 14mm thickness and black sikaflex junctions
Complete sanding + priming + new paint and varnishing of the wheelhouse and cockpit
Revision and re-varnishing of guest passageway
Complete sanding of the hull + apply of new primer + new awl grip paint + apply final clear protection coat
Dismounting portholes + re-sealing + prime + paint + re-mount
Sanding and new antifouling underwater hull
New anodes at the hull + propeller + bow thruster - Complete new service for the whole Steering system - All new engine service + generator and sea valves - Revision of the fresh water pump
New black water pump
Revision of the hydraulic bow thruster pump
New main engine alternator
Service for the generator
Service for the main engine
Inspection and service of the diesel tanks
New toilettes in owners + guest cabins
New partial paint lower mast section
Service of the all the blocks
Revision of the stay sail furling system
Complete revision of the NAVTEC hydraulic unit - New switches for the anchor winch
New paint radar antenna section
Re-mounting all the deck fittings
Complete revision of all the hydraulic deck winches - Service for all the mechanic winches
Revision of the compass
New back stays
New main sheet
New lazy jacks
Revision of the liferaft
New tenders rail
